MAN TGX 18.470 Euro 6

VEHICLE IDENTIFICATION

• Vehicle type: Truck tractor (>3.5 t)

• Manufacturer / Model: MAN TGX 18.470 Euro 6

• Type / Version: 18.470 4×2 BLS XLX (06X)

• VIN: WMA06XZZ2LP135214

• Registration number: WGM68405

• Year of manufacture: 2019 (verified via external database)

• First registration: 31.07.2019

• Next technical inspection: 10.06.2026

• Mileage (odometer): 597,480 km (read, not electronically verified)

• Gross vehicle weight: 18,000 kg

• Unladen weight: 7,791 kg

• Wheelbase: 3,900 mm

• Engine: Diesel, turbocharged with charge-air cooling

• Displacement / Power: 12,419 cc / 470 HP (346 kW)

• Emission standard: EURO 6 (SCR system)

• Gearbox: 12-speed automatic

• Cab: XLX sleeper cab, high roof

• Body color: White (solid)

TYRES

• Front axle (L/R): Michelin X LINE ENERGY Z 315/70 R22.5 – 9.0 mm

• Rear axle:

  • Left outer/inner: Continental Conti EcoPlus HD3 M+S 315/70 R22.5 – 7.0 mm

  • Right outer: Michelin X LINE ENERGY Z 315/70 R22.5 – 6.0 mm

  • Right inner: Michelin X LINE ENERGY Z 315/70 R22.5 – 3.0 mm

STANDARD EQUIPMENT (EUROTAX – SELECTED)

• ASR traction control; MAN BrakeMatic

• Differential lock; ECAS air suspension height control

• ESP stability control; EVB engine brake

• Emergency braking system (EBA)

• XLX sleeper cab (high roof), auxiliary air heater

• Automatic climate control; on-board computer

• Lane departure warning (LGS)

• Cruise control; tachograph

• Multifunction steering wheel; power steering

• Heated & electrically adjustable mirrors

• Rear axle air suspension; fog & cornering lights

(Optional equipment such as retarder, additional fuel tank, LED rear lights, heated seat, active cruise, leather steering wheel, navigation – not present.)

PAINT THICKNESS MEASUREMENTS

• All measured panels up to ~150 μm → no repainting detected (see diagram on page 5).

TECHNICAL CONDITION – KEY FINDINGS

Cab / Exterior

• Front cover: crack

• Right door: scratches

• Left door: corrosion traces

• Front bumper: scratches and deformation

• Entry steps (left & right): housing cracks

• Right fender: scratches

• Right side indicator: leakage

Cab Interior

• Steering wheel: material wear

• Cruise control buttons: material loss

• Upholstery/floor coverings: soiling

• Driver’s seat: burn mark

Chassis / Frame

• Right & left longitudinal members: corrosion traces

• Rear right mudguard: incomplete & deformed

• Rear left mudguard: crack

• Rear cross-member: corrosion

• VIN stamping area: heavy corrosion – VIN not legible
  (Identification based on the manufacturer’s plate.)

Engine & Drivetrain

• Retarder lines: corrosion traces

• Drive axle housing: corrosion traces

• Retarder: visible seepage – workshop verification required

• Engine: visible leaks – workshop verification required

• During movement test: abnormal jerking observed – to be verified

Brakes

• Front and rear brake discs: worn

Suspension & Steering

• Not fully verifiable (inspection performed under parking conditions without diagnostic stand).

TEST DRIVE

• Limited movement test performed; full road test not possible due to inspection conditions.

DOCUMENTS

• Registration certificate: PRESENT

• Service book: NOT presented

DISCLAIMERS

• Visual/organoleptic inspection only; no workshop diagnostics

• Mileage not electronically verified

• VIN correctness not examined due to corrosion at stamping area

• This report is not a purchase warranty and not a full technical expertise

• Electronically issued document – valid without signature
